Ibaiondo 03700031 700 ltr AMR PLUS Potable Expansion vessel

Part No: 03700031

Size: 700 Ltr

Click here to download a PDF spec sheet for full product details

• Maximum working pressure 10 bar
• Pre-charge 1.5 bar *
• Temperature range - 10 °C + 100 °C
• Dimensions D 700 x 2215 Height
• Water Connection 1 1/2”
• Weight 158 Kilos
• High resistant rubber bladder
• S'steel cap and sleeve
• Replaceable food industry quality bladder (the water stays inside the bladder)
• Exterior finish of oven dried with Epoxi

Epoxy powder coating
Membrane according to DIN 4807 suitable to contain sanitary water.
Fixed membrane (non-replaceable)

Expansion vessel for hot sanitary water in opened circuits.

* May require adjustment to suit installation. This adjustment must be made with the vessel isolated from the system and prior to filling with water

Approvals:- (Vessel) CE endorsed, TUV

This tank is used in the following installation cases:

Potable water applications, booster sets, borehole pumps etc, expanded water from hot water cylinders and calorifiers.

The tanks can be set up with a pump unit and pressure switch etc to reduce the number of starts and stops per hour.
