1/2" M x 3/4" F Angled Tundish

1/2" M x 3/4" F Straight Tundish – AP-400001 – WRAS Approved

WRAS approved straight tundish with 1/2" male inlet and 3/4" female outlet. Used as a visible air gap in the discharge pipework from temperature/pressure relief valves on water heaters and boilers, as required by Water Regulations.

Key Details

• Part Number: AP-400001

• Inlet: 1/2" Male BSP

• Outlet: 3/4" Female BSP

• Max operating temperature: 110°C

• Approval: WRAS approved

• Function: Air gap tundish for T&P relief valve discharge

• Supplied by Spatec NI

Installation Note

Required by UK Water Regulations where a visible air gap is needed in the discharge pipe from a temperature or pressure relief valve. Suitable for use with Zip water heaters and boilers.
