Ibaiondo 66700817 100 AMR - P - A Replacement Membrane Bladder

Ibaiondo Replacement Membrane / Bladder 66700817

Product: Replacement Membrane / Bladder for Expansion Vessel
Manufacturer: Ibaiondo
Manufacturer Part Number: 66700817
Ibaiondo Reference: 1535
Compatible Vessel: Ibaiondo 100 AMR-P-A
Vessel Capacity: 100 litres
Membrane Type: Replaceable bellows-type bladder
Application: Hydropneumatic accumulator and cold-water pressure-boosting systems

Dimensions

Approximate dimensions: Ø250 × 730 mm, with an Ø80 mm opening.

Compatibility

Designed specifically as a replacement membrane for the Ibaiondo 100 AMR-P-A, 100-litre hydropneumatic expansion vessel/accumulator.

Identification

• Model: 100 AMR-P-A
• Replacement part: Membrane / bladder
• Construction: Bellows-type replaceable membrane

Important Dimensional Note

Ibaiondo's older documentation lists the same part number, 66700817, with dimensions of approximately 250 × 680 × 87 mm. Later Ibaiondo documentation specifies 250 × 730 × 80 mm.

For purchasing and compatibility purposes, part number 66700817 should be used as the primary identification.

Manufacturer Documentation

The dimensions above are based on Ibaiondo's official spare-parts documentation and product catalogues.
